outdoor pitch 4.81mm led display
|
Model No. |
P4.81 |
P5.95 |
P6.94 |
P8.33 |
P8.93 |
P12.5 |
P15.625 |
|
Pixel Pitch |
4.81mm |
5.95mm |
6.94mm |
8.33mm |
8.93mm |
12.5mm |
15.625mm |
|
Pixel Configuration |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
|
LED Encapsulation |
SMD2427 |
SMD3528 |
SMD3528 |
SMD3535 |
SMD3528 |
SMD3528 |
SMD3535 |
|
Resolution |
43264dots/㎡ |
28224dots/㎡ |
20736dots/㎡ |
14400dots/㎡ |
12544dots/㎡ |
6400dots/㎡ |
4096dots/㎡ |
|
Brightness |
900-1100nit |
900-1100nit |
700-1100nit |
4500-5500nit |
900-1100nit |
900-1100nit |
4500-5000nit |
|
Color Temperature |
6500-9000K |
6500-9500K |
6500-9000K |
6500-9000K |
6500-9500K |
6500-9500K |
6500-9000K |
|
Drive Mode |
1/13 |
1/7 |
1/9 |
1/3 |
1/7 |
static |
static |
|
Module size |
500*250mm |
500*250mm |
500*250mm |
500*250mm |
500*250mm |
500*250mm |
500*250mm |
|
Cabinet Size |
500*1000*75mm |
500*1000*75mm |
500*1000*75mm |
500*1000*75mm |
500*1000*75mm |
500*1000*75mm |
500*1000*75mm |
|
Cabinet Resolution |
104*208 |
84*168 |
72*144 |
60*120 |
56*112 |
40*80 |
32*64 |
|
Cabinet Weight |
10.5kg |
10.5kg |
10.5kg |
11.5kg |
10.5kg |
10.5kg |
10.5kg |
|
Max Power |
≤520w/㎡ |
≤520w/㎡ |
≤520w/㎡ |
≤560w/㎡ |
≤520w/㎡ |
≤560w/㎡ |
≤520w/㎡ |
|
Average Power |
≤260w/㎡ |
≤260w/㎡ |
≤260w/㎡ |
≤280w/㎡ |
≤260w/㎡ |
≤280w/㎡ |
≤260w/㎡ |
|
Best Viewing Angle |
H:160°V:140° |
H:160°V:140° |
H:160°V:140° |
H:160°V:140° |
H:160°V:140° |
H:160°V:140° |
H:160°V:140° |
|
Refresh Rate |
1000-1920Hz |
1000-1920Hz |
1000-1920Hz |
1920-4800Hz |
1000-1920Hz |
1000-4800Hz |
1000-1920Hz |
|
Grey Scale |
14bit |
14bit |
14bit |
14bit |
14bit |
14bit |
14bit |
|
Best Viewing Distance |
8--50m |
8--50m |
8--50m |
8--50m |
8--50m |
10--50m |
10--50m |
|
Protection Level |
IP31 |
IP65/IP54 | |||||
|
Cabinet Material |
Die casting Aluminum | ||||||
|
Operation Voltage |
100V/220V/47-63Hz | ||||||
|
Working Humidity |
10﹪-60﹪ |
10﹪-90﹪ | |||||
|
Working Temperature |
–20℃--+50℃ | ||||||
