outdoor pitch 8.93mm led display
|
Model No. |
P8.93 |
P10.42 |
P8.33 |
P10.42 |
|
Pixel Pitch |
8.93mm |
10.42mm |
8.33mm |
10.42mm |
|
Pixel Configuration |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
|
LED Encapsulation |
SMD3528 |
SMD3528 |
SMD3535 |
SMD3535 |
|
Resolution |
12544dots/㎡ |
9216dots/㎡ |
14400dots/㎡ |
9216dots/㎡ |
|
Brightness |
≥1300nit |
≥1300nit |
4000-5000nit |
4000-5000nit |
|
Color Temperature |
3200-9500K |
3200-9500K |
3200-9500K |
3200-9500K |
|
Drive Mode |
1/7 |
1/6 |
1/3 |
1/2 |
|
module size |
250*250mm |
250*250mm |
250*250mm |
250*250mm |
|
Cabinet Size |
500*500*76mm |
500*500*76mm |
500*500*76mm |
500*500*76mm |
|
Cabinet Resolution |
56*56 |
48*48 |
60*60 |
48*48 |
|
Cabinet Weight |
10kg |
10kg |
10kg |
10kg |
|
Max Power consumption |
≤540w/㎡ |
≤500w/㎡ |
≤560w/㎡ |
≤500w/㎡ |
|
Average Power consumption |
≤270w/㎡ |
≤250w/㎡ |
≤280w/㎡ |
≤250w/㎡ |
|
Best Viewing Angle |
H:140°V:120° |
H:140°V:120° |
H:140°V:120° |
H:140°V:120° |
|
Refresh Rate |
1920-2500Hz |
1920-2500Hz |
1920-2500Hz |
1920-2500Hz |
|
Grey Scale |
14bit |
14bit |
14bit |
14bit |
|
Best Viewing Distance |
8--50m |
10--50m |
8--50m |
10--50m |
|
Protection Level |
|
IP65/IP54 | ||
|
Cabinet Material |
|
Die casting Aluminum | ||
|
Operation Voltage |
|
220V/50Hz,110V/60HZ | ||
|
Working Humidity |
|
10﹪-90﹪ | ||
|
Working Temperature |
|
–20℃--+55℃ | ||
